Honeywell Analytics MIDAS Sensor

Honeywell Analytics MIDAS Sensor Cartridge Carbon Dioxide (CO2) - MIDAS - I - CO2
Product Overview:
The Midas Gas Detector uses reliable sensor technology to detect many key toxic, ambient and flammable gases in a plant. The device monitors points up to 100 feet (30 meters) away while using patented technology to regulate flow rates and ensure error - free gas detection.
Improved visibility and ease of use. The Midas Gas Detector is equipped with bright LED lights and an intuitive, interactive interface that provides instant alerts to gas readings or alarm levels. The interface also includes password - protected menus for configuration, test and calibration.
Easy installation. Compact in size with an easy - to - handle metal chassis, the Midas Gas Detector is simple to install. That’s especially important in crowded, complex process environments where space is at a premium.
Numerous applications. With feature - rich capabilities that are easy to use, the Midas Gas Detector is suitable for many industry applications, including semiconductor processing, light industrial manufacturing, university laboratories, aerospace, wastewater and more.
Email: Mia@cwlyautomation. com
VK/Whatsapp/Telegram: +8613667120925
Website: www. cwlyautomation. com
Gas Measured Carbon Dioxide (CO2）
Cartridge Part Number MIDAS - I - CO2
Sensor Technology Nondispersive Infrared (NDIR) sensor
Measuring Range (%VOL) CO2
0 – 2. 0%VOL CO2
0 – 5. 0%VOL CO2
0 – 0. 2%VOL
Minimum Alarm 1 Set Point 0. 25%VOL 0. 25%VOL 0. 025%VOL
Lower Detectable Limit (LDL) 0. 15%VOL 0. 15%VOL 0. 015%VOL
Repeatability < ± 5% of measured value @20°C (68°F) ambient
Resolution 0. 01%VOL 0. 01%VOL 0. 001%VOL
Linearity < ± 10% of measured value
Response Time (T90) <30s @20°C (68°F) ambient
Sensor Cartridge Life Expectancy 5 years
Operating Temperature 0°C to +40°C (32°F to 104°F)
Operating Humidity (continuous) 0 to 95% non - condensing
Operating Pressure 90 – 110kPa
Effect of Position No effect in typical application
Calibration Gas Carbon Dioxide (CO2)
Challenge Gas (Bump Test) Carbon Dioxide (CO2)
Warm up time To final zero ± 0. 01%Vol: <10min
Storage Temperature - 20°C to +50°C (- 4°F to +122°F)
Email: Mia@cwlyautomation. com
VK/Whatsapp/Telegram: +8613667120925
Website: www. cwlyautomation. com
Additional Features and Benefits:
Over 35 gases available with extended 2 year warranty *
Smart sensor cartridge with on board ‘e - calibration’ certificate
3 built in relays (Form C) for Alarm 1,2 and Fault
Power over Ethernet (PoE) communication
Keypad interface and remote web browser interface
Optional Midas Pyrolyzer module that connects to any Midas Gas Detector
Password protected menu levels to preserve system integrity
Bright LEDs and intuitive icon driven, large multicolor backlit LCD display
Factory - calibrated sensors to reduce need for frequent gas testing
Isolated 0 - 22 mA analog output with fault and event reporting
Modbus/TCP Ethernet for easy connectivity to all control and alarm systems ports for control connectivity and service interaction
Robust extractive pump system (2 year lifetime) sampling up to 100 feet
CE marked for total immunity to Radio Frequency Interference
Reflex® sensor health check for improved safety
TempraSureTM temperature compensation technology as appropriate
Event logging to review sensor history
Please contact me get more information
Email: Mia@cwlyautomation. com
VK/Whatsapp/Telegram: +8613667120925
Website: www. cwlyautomation. com
